Informasi
Ikhtisar
Basic Specs
Keyboard
QWERTY
Media Type
TZe tape, HSe tape
Available Tape Widths
6 mm, 9 mm, 12 mm, 18 mm
Dimension (Width x Depth x Height)
134 mm x 69 mm x 221 mm
Weight
0.75 kg
Warranty
3 years / 36 months
Print Output
Print Resolution
180 dpi
Print Speed
20 mm/sec
No. of Lines Printable
18 mm tape: 1 - 5 lines;
12 mm tape: 1 - 3 lines;
9 mm tape: 1 - 2 lines;
6 mm tape: 1 - 2 lines;
3.5 mm tape: 1 line
Number of Characters
591
Number of Symbols
384
Bar Code
1. CODE39
2. ITF 2/5
3. EAN13
4. EAN8
5. UPC-A
6. UPC-E
7. CODABAR
8. GS1-128 (UCC/EAN128)
9. CODE128
Numbering
Yes
Media
Tape Cassette
Up to 18 mm
Functions
Cutter
Manual
Multi-block Printing
Yes
Copy Printing
Yes
Mirror Printing
Yes
Preview
Yes
Memory
File Storage
Maximum 50 files
Memory Buffer Size
Maximum 2,400 characters
Power Supply
Power Supply
6 AA alkaline batteries (LR6), 6 AA Ni-MH rechargeable batteries (HR6), Li-ion Battery (BA-E001), or AC adapter(AD-E001)
Auto Power-off
Battery: 5 min
AC adapter: 5 min
AC Adaptor
AD-E001
Interface
Button
Keyboard
Display
16 characters x 2 guidance and 2 lines text
(128 dots x 56 dots)
Backlight
Yes
Connectivity
USB
No
Wireless LAN
No
Spesifikasi
Basic Specs
Keyboard
QWERTY
Display Type
16 characters x 2 guidance and 2 lines text
(128 dots x 56 dots)
Media Type
TZe tape, HSe tape
Available Tape Widths
3.5 mm, 6 mm, 9 mm, 12 mm, 18 mm
Dimensi Produk (Lebar X Kedalaman X Tinggi)
134 mm × 69 mm × 221 mm
Berat
0.75 kg
KecepatanCetak
20 mm/sec
Garansi
3 years / 36 months
Spesifikasi-Cetak
Resolution
180 dpi
No. Of Printable Lines
18 mm tape: 1 - 5 lines;
12 mm tape: 1 - 3 lines;
9 mm tape: 1 - 2 lines;
6 mm tape: 1 - 2 lines;
3.5 mm tape: 1 line
Number of Characters
591
Number of Symbols
384
Barcode
1. CODE39
2. ITF 2/5
3. EAN13
4. EAN8
5. UPC-A
6. UPC-E
7. CODABAR
8. GS1-128 (UCC/EAN128)
9. CODE128
Numbering
Yes
Media
Maximum Tape Width
Up to 18 mm
Functions
Cutter
Manual
Multi Block Printing
Yes
Copy Printing
Yes
Mirror Printing
Yes
Preview
Yes
Memory
File Storage
Maximum 50 files
Memory Buffer Size
Maximum 2,400 characters
Power
Power Source
6 AA alkaline batteries (LR6), 6 AA Ni-MH rechargeable batteries (HR6), Li-ion Battery (BA-E001), or AC adapter(AD-E001)
Auto Power-Off
Battery: 5 min
AC adapter: 5 min
