Basic Specs
< div="" class="function-list">
Keyboard
QWERTY
Media Type
TZe tape, HSe tape
Available Tape Widths
TZe: 3.5, 6, 9, 12, 18, 24mm, HGe: 6, 9, 12, 18, 24mm, HSe: 5.8, 8.8, 11.7, 17.7, 23.6mm
Dimension (Width x Depth x Height)
125.8 mm x 94.1 mm x 249.9 mm
Weight
1.05 kg
Warranty
3 years / 36 months
Print Output
Print Resolution
180 dpi
Print Speed
30 mm/sec
No. of Lines Printable
24 mm tape: 1 - 7 lines;
18 mm tape: 1 - 5 lines;
12 mm tape: 1 - 3 lines;
9 mm tape: 1 - 2 lines;
6 mm tape: 1 - 2 lines;
3.5 mm tape: 1 line
Number of Characters
591
Number of Symbols
384
Bar Code
1. CODE39
2. ITF 2/5
3. EAN13
4. EAN8
5. UPC-A
6. UPC-E
7. CODABAR
8. GS1-128 (UCC/EAN128)
9. CODE128
Numbering
Yes
Media
Tape Cassette
Up to 24 mm
Functions
Cutter
Auto (half and full)
Multi-block Printing
Yes
Copy Printing
Yes
Mirror Printing
Yes
Preview
Yes
Memory
File Storage
Maximum 99 files (local)
Maximum 99 templates, databases, and images each (total of 6MB)
Memory Buffer Size
Maximum 18,297 characters
Power Supply
Power Supply
6 AA alkaline batteries (LR6), 6 AA Ni-MH
rechargeable batteries (HR6), Li-ion Battery (BA-E001), or AC
adapter (AD-E001)
Auto Power-off
6 AA alkaline batteries (LR6)/6 AA Ni-MH rechargeable
batteries (HR6): 20 min;
Li-ion battery (BA-E001): 30 min;
AC adapter (AD-E001): 60 min
AC Adaptor
AD-E001
Interface
Button
Keyboard
Display
15 characters x 2 lines and guidance area
(128 dots x 64 dots)
Backlight
Yes
Connectivity
USB
Yes
Wireless LAN
Yes
Spesifikasi
Basic Specs
Keyboard
QWERTY
Display Type
15 characters x 2 lines and guidance area
(128 dots x 64 dots)
Media Type
TZe tape, HSe tape
Available Tape Widths
TZe: 3.5, 6, 9, 12, 18, 24mm, HGe: 6, 9, 12, 18, 24mm, HSe: 5.8, 8.8, 11.7, 17.7, 23.6mm
Dimensi Produk (Lebar X Kedalaman X Tinggi)
125.8 mm × 94.1 mm × 249.9 mm
Berat
0.92 kg
KecepatanCetak
30 mm/sec
Garansi
3 years / 36 months
Spesifikasi-Cetak
Resolution
180 dpi
No. Of Printable Lines
24 mm tape: 1 - 7 lines;
18 mm tape: 1 - 5 lines;
12 mm tape: 1 - 3 lines;
9 mm tape: 1 - 2 lines;
6 mm tape: 1 - 2 lines;
3.5 mm tape: 1 line
Number of Characters
591
Number of Symbols
384
Barcode
1. CODE39
2. ITF 2/5
3. EAN13
4. EAN8
5. UPC-A
6. UPC-E
7. CODABAR
8. GS1-128 (UCC/EAN128)
9. CODE128
Numbering
Yes
Connectivity
Connectivity
USB, Wireless LAN
Media
Maximum Tape Width
Up to 24 mm
Functions
Cutter
Auto (half and full)
Multi Block Printing
Yes
Copy Printing
Yes
Mirror Printing
Yes
Preview
Yes
Memory
File Storage
Maximum 99 files (local)
Maximum 99 templates, databases, and images each (total of 6MB)
Memory Buffer Size
Maximum 18,297 characters
Power
Power Source
6 AA alkaline batteries (LR6), 6 AA Ni-MH
rechargeable batteries (HR6), Li-ion Battery (BA-E001), or AC
adapter (AD-E001)
Auto Power-Off
6 AA alkaline batteries (LR6)/6 AA Ni-MH rechargeable
batteries (HR6): 20 min;
Li-ion battery (BA-E001): 30 min;
AC adapter (AD-E001): 60 min
