IDR 11.290.000
- Cetak Label TZe Berlaminasi Hingga 36mm dan φ 2.5 - φ 6.5 PVC Tubes
- Fungsi Potong Otomatis dan Potong Setengah
- Mesin ganda untuk cetak tube dan label
- Pembersih, pemotong, dan rol tabung yang dapat diganti sendiri
- Baterai Li-ion Isi Ulang opsional
Belanja Sekarang di Brother Official Store:
Informasi
Ikhtisar
Basic Specs
Keyboard
QWERTY
Media Type
TZe Laminated Tape, HGe Laminated Tape, HSe Heat Shrink Tube
Available Tape Widths
TZe: 3.5, 6, 9, 12, 18, 24, 36mm, HGe: 6, 9, 12, 18, 24, 36mm, HSe: 5.8, 8.8, 11.7, 17.7, 23.6mm
Dimension (Width x Depth x Height)
338 mm x 188 mm x 173 mm
Weight
4.6 kg
Warranty
3 years / 36 months
Print Output
Print Resolution
360 dpi
Print Speed
Tube printing: 40mm/sec
Label printing: 60mm/sec
No. of Lines Printable
Tube: 2 lines
Label: 17 lines
Number of Characters
826
Number of Symbols
465
Bar Code
22 barcode protocols on P-touch Editor 5.1
Functions
Cutter
Auto and half cutter
Mirror Printing
Yes
Memory
File Storage
99 files
Memory Buffer Size
up to 40,000 chrs
Power Supply
Power Supply
AC adapter (AD9100ESA): 24 V AC 100-240 V 50/60 Hz,
Battery: Li-ion Battery (PA-BT-4000LI): 14.4 V
Auto Power-off
Li-ion Battery (PA-BT-4000LI): 30 min
AC Adaptor
AD9100ESA
Connectivity
USB
Version 2.0 Full Speed
Wireless LAN
Wireless Direct: IEEE 802.11n
Ad-Hoc mode: IEEE 802.11b
Infrastructure mode: IEEE 802.11b/g/n
WPS 2.0
Spesifikasi
Basic Specs
Keyboard
QWERTY
Media Type
TZe Laminated Tape, HGe Laminated Tape, HSe Heat Shrink Tube
Available Tape Widths
TZe: 3.5, 6, 9, 12, 18, 24, 36mm, HGe: 6, 9, 12, 18, 24, 36mm, HSe: 5.8, 8.8, 11.7, 17.7, 23.6mm
Dimensi Produk (Lebar X Kedalaman X Tinggi)
338 mm × 188 mm × 173 mm
Berat
4.6 kg
KecepatanCetak
Tube printing: 40mm/sec
Label printing: 60mm/sec
Garansi
3 years / 36 months
Spesifikasi-Cetak
Resolution
360 dpi
No. Of Printable Lines
Tube: 2 lines
Label: 17 lines
Number of Characters
826
Number of Symbols
465
Barcode
22 barcode protocols on P-touch Editor 5.1
Connectivity
Connectivity
USB version 2.0 (Full Speed), Wireless LAN IEEE 802.11b/g/n (Infrastructure Mode), IEEE 802.11b (Ad-Hoc Mode), IEEE 802.11n (Wireless Direct), WPS 2.0
Media
Maximum Tape Width
Up to 36 mm
Functions
Cutter
Auto and half cutter
Mirror Printing
Yes
Memory
File Storage
99 files
Memory Buffer Size
up to 40,000 chrs
Power
Power Source
AC adapter (AD9100ESA): 24 V AC 100-240 V 50/60 Hz,
Battery: Li-ion Battery (PA-BT-4000LI): 14.4 V
Auto Power-Off
Li-ion Battery (PA-BT-4000LI): 30 min
